Bose L1 Pro16 Service Manual

32
POWER-AMP PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C176, C197, C199, C201 CAP, EL, SMT, 105C, 16V, 20%, 10uF, COMM 856752-
100M1CAB
C17X, C17Y, C17Z, C18X,
C18Y, C18Z, C193X,
C193Y, C193Z, C194X,
C194Y, C194Z, C22X,
C22Y, C22Z, C23X, C23Y,
C23Z, C27X, C27Y, C27Z
CAP, X7R, 0603, 100V, 10%, 0.1uF, COMM 718875-104K2A
C19, C72-C73, C78,
C82, C94, C115-C118,
C132-C133, C142-C143,
C149-C150, C173, C10X,
C10Y, C10Z, C3X, C3Y,
C3Z, C7X, C7Y, C7Z
CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
C24X, C24Y, C24Z CAP, FILM, LS 5mm, AMMO, 5%, 100V, 1uF 329288-1004BJA
C25X, C25Y, C25Z CAP, X7R, 0805, 100V, 20%, 0.01uF, COMM 763872-103M2A
C26X, C26Y, C26Z CAP, C0G, 0805, 100V, 5%, 1000pF, COMM 763940-102J2A
C28, C32, C34, C38, C42,
C46
CAP, C0G, 0603, 50V, 5%, 680pF, COMM 780788-681J1H
C29-C30, C43-C44, C152,
C154, C156
CAP, C0G, 0603, 50V, 5%, 470pF, COMM 780788-471J1H
C31, C37, C45 CAP, X7R, 0603, 50V, 10%, 3300pF, COMM 718875-332K1H
C39, C77, C93, C151, C203 CAP, X7R, 0603, 50V, 5%, 10000pF, COMM 718875-103J1H
C4, C11, C13, C35-C36,
C40-C41, C104-C105,
C110-C112, C125, C138,
C140, C147, C183, C188,
C190-C191
CAP, X7R, 0603, 50V, 10%, 0.1uF, COMM 718875-104K1H
C48, C62, C64 CAP, X7R, HI VOLT, 0805, 630V, 10%, .01uF,
COMM
852020-103K2J
C49-C50 CAP, EL, SNAP-IN, 450V, 20%, 330uF 853707-
331M2WCC
3
C52-C53, C120, C129,
C141
CAP, EL, POLYMER, SMT, 25V, 20%, 47uF,
COMM
857020-
470M1EAA
C55, C67, C76, C177 CAP, FILM, PFC, 15mm, BULK 6mm, 630V,
10%, 1uF
856507-
105K2JBB
C61, C123, C159 CAP, X7R, HI V, 1206, 1000V, 10%, 4700pF,
COMM
852057-472K3A
C65-C66 CAP, C0G, 0603, 50V, 5%, 47pF, COMM 780788-470J1H
C68, C70-C71, C131, C139,
C146, C6X, C6Y, C6Z, C8X,
C8Y, C8Z, C9X, C9Y, C9Z
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C69, C101, C107 CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
C74 CAP, X7R, 0603, 50V, 10%, 0.068uF, COMM 718875-683K1H
C79 CAP, X7R, 0603, 16V, 10%, 0.47uF, COMM 718875-474K1C
C80, C102 CAP, C0G, 0805, 250V, 5%, 100pF, COMM 763940-101J2E

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
