Bose L1 Pro16 Service Manual

33
POWER AMP PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C83 CAP, C0G, 0603, 50V, 5%, 330pF, COMM 780788-331J1H
C84, C95, C134X, C134Y,
C134Z, C144X, C144Y,
C144Z, C15X, C15Y, C15Z,
C16X, C16Y, C16Z, C20X,
C20Y, C20Z, C21X, C21Y,
C21Z
CAP, X7R, 0805, 100V, 10%, 0.47uF, COMM 763872-474K2A
C85-C87, C96-C98 CAP, EL, LOW Z, 18x25mm, 80V, 20%, 820uF 853760-821M1K-
GG
C88, C91 CAP, X7R, HI VOLT, 0805, 500V, 10%, 220pF,
COMM
852020-221K2H
C89,C136-C137,C175 CAP, X7R, 0603, 100V, 10%, 1000pF, COMM 718875-102K2A
C90 CAP, C0G, HI VOLT, 1206, 500V, 5%, 15pF,
COMM
777098-150J2H
C92 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
C99-C100 CAP, FILM, HI V, 15mm, BULK, 1000V, 5%,
0.68uF
856510-
683J3ABB
CX1-CX3 CAP, FILM, X2, LS 15mm, 305VAC, 20%,
0.47uF
310415-474MG 3
CY1-CY2 CAP, CER, X1/Y1, Bulk 25mm, 10%, 330pF 855444-331KG 3
CY3-CY4,CY6 CAP, CER, X1/Y1, Bulk 5mm, 20%, 1000pF 855444-102MN 3
CY5 CAP, CER, X1/Y1, Bulk 25mm, 10%, 470pF 855444-471KG 3
Diodes
Reference Designator Description Material Number Note
BD1 DIODE, BRIDGE RECTIFIER, 25A, 800V, SIP 842301-0800 3
D19-D21, D24 DIODE, RECT, S-FAST, 400V, 10A, TPMR10G,
SMPC
855873-0400
D23 DIODE, ZENER, 0.2W, 15V, 5%, SOD-323F 856094-15V0
D25-D26 DIODE, ZENER, 0.5W, 2.4V, 2%, SOD-123F 856111-02V4
D27 DIODE, RECT, ULTRAFAST, 200V, 6A,
TPUH6D, SMPC
855862-0200
D28 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D29, D42, D45 DIODE, ZENER, 0.5W, 5%, 24V, SOD-123 174265-5252
D3, D13-D14, D33, D35,
D43-D44
DIODE, RECT, FAST, 1000V, 0.8A, RS1ML,
FLSMA
856386-1000
D30-D31 DIODE, RECT, FAST, 1000V, 1A 317066-1000
D32, D34, D1X, D1Y, D1Z,
D2X, D2Y, D2Z
DIODE, RECT, 200V, 1A, ESH1DM, SMA 849894-0100
D36 DIODE, ZENER, 0.2W, 12V, 2%, SOD-323F 856105-12V0
D39 DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
D4, D12, D18, D22,
D37-D38, D40, D41X, D41Y,
D41Z, D5X, D5Y, D5Z
DIODE, SWITCHING, 100V, 0.15A, SOD323F 856395-0010
