Bose L1 Pro32 Service Manual

20
MAIN-I/O PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R364, R195A, R195B,
R202A, R202B, R208A,
R208B, R209A, R209B,
R211A, R211B, R247A,
R247B, R252A, R252B,
R253A, R253B, R257A,
R257B, R260A, R260B
RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R37, R50, R54, R68 RES, THICK FILM, 0603, 0.1W, 1%, 14K 857326-0106
R375, R379, R383 RES, THICK FILM, 0603, 0.1W, 1%, 560 OHM 857326-0165
R38, R41 RES, THICK FILM, 0603, 0.1W, 1%, 20K 857326-0120
R39, R45, R55, R62 RES, THICK FILM, 0603, 0.1W, 1%, 120K 857326-0102
R397, R425 RES, THICK FILM, 0402, 0.063W, 1%, 4.7K 857326-0070
R4, R15, R88, R99, R114,
R117, R130, R277, R292,
R370, R385, R400, R424,
R256A, R256B, R262A,
R262B, R291A, R291B
JUMPER, CHIP, 0603 857326-0218
R40, R46, R56, R63, R105,
R217A, R217B, R220A,
R220B, R225A, R225B,
R239A, R239B, R241A,
R241B, R243A, R243B
RES, THICK FILM, 0603, 0.1W, 1%, 10 OHM 857326-0181
R406 RES, THICK FILM, 0603, 0.1W, 1%, 68.1 OHM 857326-0173
R408, R258A, R258B,
R259A, R259B
RES, THICK FILM, 0603, 0.1W, 1%, 267 OHM 857326-0134
R409 RES, THICK FILM, 0603, 0.1W, 1%, 110 OHM 857326-0098
R413 RES, THICK FILM, 0603, 0.1W, 1%, 750 OHM 857326-0174
R42, R49, R59, R67, R163,
R166, R210A, R210B,
R232A, R232B
RES, THICK FILM, 0603, 0.1W, 1%, 2.2K 857326-0127
R431 RES, THICK FILM, 0402, 0.063W, 1%, 2.2K 857326-0044
R44, R47, R60, R64, R281,
R391-R392, R418, R212A,
R212B, R218A, R218B,
R228A, R228B, R244A,
R244B, R249A, R249B,
R261A, R261B
RES, THICK FILM, 0603, 0.1W, 1%, 4.7K 857326-0155
R462-R463, R464A, R464B RES, THICK FILM, 0402, 0.063W, 1%, 1.5K 857326-0030
R466A, R466B, R467A,
R467B
RES, THICK FILM, 0402, 0.063W, 1%, 360
OHM
857326-0059
R48, R66, R80, R86, R159,
R233A, R233B, R74C,
R74D, R77C, R77D
RES, THICK FILM, 0603, 0.1W, 1%, 47K 857326-0156
R51, R69 RES, THICK FILM, 0603, 0.1W, 1%, 2.4K 857326-0132
R52, R70, R123-R124,
R191, R236A, R236B
RES, THICK FILM, 0402, 0.063W, 1%, 1K 857326-0020
R58, R61, R173, R270,
R306, R315, R323, R366,
R415, R227A, R227B,
R234A, R234B
RES, THICK FILM, 0603, 0.1W, 1%, 100K 857326-0094

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
