Bose L1 Pro32 Service Manual

21
MAIN-I/O PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R71, R83-R84, R97 RES, THICK FILM, 0603, 0.1W, 1%, 18K 857326-0116
R72, R75, R79, R89, R92,
R96, R284, R201A, R201B,
R264A, R264B, R325C,
R325D, R328C, R328D,
R331C, R331D, R334C,
R334D, R337C, R337D,
R340C, R340D
RES, THICK FILM, 0603, 0.1W, 1%, 100 OHM 857326-0091
R73, R78, R90, R95,
R326C, R326D, R330C,
R330D, R335C, R335D,
R339C, R339D
RES, THICK FILM, 0603, 0.1W, 1%, 6.2K 857326-0170
R76, R93 RES, THICK FILM, 0603, 0.1W, 1%, 47 OHM 857326-0159
R81-R82, R85, R87 RES, THICK FILM, 0603, 0.1W, 1%, 470 OHM 857326-0154
R98, R102, R104, R107,
R112, R122, R176, R180,
R187-R190, R192-R193,
R342-R346, R412,
R426-R427
RES, THICK FILM, 0402, 0.063W, 1%, 10K 857326-0021
Capacitors
Reference Designator Description Material Number Note
C1, C9, C13, C15-C16,
C20-C21, C57-C59,
C62-C64, C89, C93, C97,
C99, C121, C124, C199,
C208, C212-C213, C224,
C226-C227, C236-C237,
C239-C240, C252-C253,
C293-C294, C300, C134A,
C134B, C135A, C135B,
C136A, C136B, C137A,
C137B, C148A, C148B,
C149A, C149B, C150A,
C150B, C151A, C151B,
C174A, C174B, C269C,
C269D, C271C, C271D
CAP, X7R, 0402, 25V, 10%, 0.1uF, COMM 718866-104K1E
C104-C105, C107-C108,
C122-C123, C192-C193,
C230-C231, C288-C289
CAP, X7R, 0603, 6.3V, 10%, 4.7uF, COMM 718875-475K0J
C11, C96, C119 CAP, X7R, 0603, 6.3V, 10%, 1uF, COMM 718875-105K0J
C12, C23, C26, C32, C34,
C36, C40-C41, C48, C51,
C53, C68, C87, C91
CAP, EL, SMT, 105C, 16V, 20%, 22uF, COMM 856752-
220M1CBB
C125 CAP, C0G, 0402, 50V, 5%, 1000pF, COMM 766718-102J1H
C138A, C138B, C145A,
C145B
CAP, C0G, 1206, 50V, 5%, 0.1uF, COMM 852048-104J1H
C141A, C141B, C157A,
C157B, C167A, C167B,
C179A, C179B
CAP, C0G, 0603, 50V, 5%, 2700pF, COMM 780788-272J1H
