22
MAIN-I/O PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C142A, C142B, C144A,
C144B, C161A, C161B,
C172A, C172B
CAP, EL, LOW Z, SMT, 63V, 20%, 22uF, COMM 856727-
220M1JCD
C158A, C158B, C175A,
C175B
CAP, C0G, 0603, 50V, 5%, 270pF, COMM 780788-271J1H
C162A, C162B CAP, EL, SMT, 105C, 10V, 20%, 1000uF,
COMM
856752-
102M1AED
C165A, C165B CAP, C0G, 0603, 50V, 5%, 10pF, COMM 780788-100J1H
C168A, C168B, C169A,
C169B
CAP, X7R, 1206, 100V, 10%, 2.2uF, COMM 770764-225K2A
C17, C22, C66, C72, C86,
C309
CAP, X5R, 0402, 25V, 20%, 1uF, COMM 716994-105M1E
C181A, C181B, C186A,
C186B, C90A, C90B
CAP, X7R, 0603, 50V, 10%, 0.1uF, COMM 718875-104K1H
C190-C191, C210-C211,
C217-C218, C233-C234,
C243-C244, C250-C251
CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
C194 CAP, X7R, 0805, 100V, 10%, 0.1uF, COMM 763872-104K2A
C195 CAP, EL, SMT, 105C, 100V, 20%, 33uF, COMM 856752-
330M2AED
C204 CAP, C0G, 0603, 50V, 5%, 330pF, COMM 780788-331J1H
C209 CAP, X7R, 0603, 16V, 10%, 0.47uF, COMM 718875-474K1C
C229 CAP, C0G, 0402, 50V, 5%, 22pF, COMM 766718-220J1H
C241 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
C242 CAP, C0G, 0603, 50V, 5%, 82pF, COMM 780788-820J1H
C24-C25, C28-C29,
C43-C44, C46-C47, C73,
C77-C78, C82, C140A,
C140B, C143A, C143B,
C166A, C166B, C260C,
C260D, C263C, C263D
CAP, C0G, 0603, 50V, 5%, 470pF, COMM 780788-471J1H
C27, C35, C42, C52,
C155A, C155B, C164A,
C164B, C170A, C170B,
C173A, C173B
CAP, C0G, 0603, 50V, 5%, 100pF, COMM 780788-101J1H
C291-C292 CAP, C0G, 0402, 50V, 5%, 15pF, COMM 766718-150J1H
C2-C3, C6, C14, C18-C19,
C98, C101, C132, C215,
C249, C152A, C152B,
C153A, C153B, C183A,
C183B, C184A, C184B
CAP, X5R, 0603, 10V, 10%, 10uF, COMM 718835-106K1A
C30, C39, C49, C56 CAP, X7R, 0402, 50V, 10%, 0.1uF, COMM 718866-104K1H
C301-C302 CAP, C0G, 0603, 50V, 5%, 47pF, COMM 780788-470J1H
C5, C196, C205, C225,
C228, C235, C238, C245,
C310
CAP, EL, SMT, 105C, 25V, 20%, 100uF, COMM 856752-
101M1ECC
To Next Page
