Bose L1 Pro32 Service Manual

23
MAIN-I/O PCB PARTS LIST
Capacitors (continued)
Diodes
Reference Designator Description Material Number Note
C65, C69, C83, C95, C100,
C102, C106, C109-C118,
C120, C126-C131, C202,
C214, C273-C277,
C285-C287, C304
CAP, X7R, 0402, 50V, 10%, 10000pF, COMM 718866-103K1H
C67, C76, C79, C88,
C185A, C185B, C187A,
C187B, C188A, C188B,
C189A, C189B
CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C71, C85, C216, C258C,
C258D, C266C, C266D
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C8, C10, C60-C61,
C74-C75, C80-C81, C203,
C133A, C133B, C146A,
C146B, C154A, C154B,
C163A, C163B, C177A,
C177B, C182A, C182B,
C255C, C255D, C261C,
C261D, C262C, C262D,
C268C, C268D
CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
Reference Designator Description Material Number Note
D15 DIODE, RECT, 200V, 1A, ESH1DM, SMA 849894-0100
D17 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D18, D25 DIODE, SCHOTTKY, 40V, 1A, SS14L, FLSMA 855980-0040
D1-D4, D19, D12A, D12B,
D13A, D13B, D14A, D14B,
D9A, D9B
DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
D20 DIODE, TVS, BIDIR, DUAL, 24V, ESDCAN01,
SOT23, AUTO
855760-0010
D22, D26, D10A, D10B,
D11A, D11B
DIODE, SWITCHING, 100V, 0.15A, SOD323F 856395-0010
D37A, D37B, D38A, D38B DIODE, TVS, 58V, 400W, BI-DIR, SMAJ58CA 310546-058
D42 DIODE, SCHOTTKY, 2A, 40V, SMA 852396-240A
D43 DIODE, SCHOTTKY, 30V, BAT54A, SOT-23 330427-0020
D5-D6, D8, D16, D21,
D23-D24, D27-D34, D39,
D35A, D35B, D36A, D36B
VARISTOR, MULTILAYER, 0402, 130pF, 12V 855757-120M131
LED15 DIODE, LED, 0603, BLUE, VERT 851299-0010
LED17 DIODE, LED, 0606, WHITE, RED, VERT 851297-0010
LED1-LED3, LED5, LED8,
LED10-LED14, LED16
DIODE, LED, 0603, WHITE, VERT 851300-0010
LED4, LED6-LED7, LED9 DIODE, LED, 0603, WHITE, GREEN, VERT 851298-0010
