POWER-AMP PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R30, R259-R261 RES, THICK FILM, 1206, 0.25W, 1%, 3.3M 857326-0206
R34-R35, R275 RES, THICK FILM, 0603, 0.1W, 1%, 22K 857326-0128
R40 RES, THICK FILM, 0603, 0.1W, 1%, 220 OHM 857326-0126
R44 RES, THICK FILM, 0603, 0.1W, 1%, 110K 857326-0099
R45, R64, R89 RES, THICK FILM, 0603, 0.1W, 1%, 47K 857326-0156
R46 RES, THICK FILM, 0603, 0.1W, 1%, 133K 857326-0104
R47, R72, R79, R87 RES, THICK FILM, 0603, 0.1W, 1%, 100K 857326-0094
R48 RES, THICK FILM, 0603, 0.1W, 1%, 130K 857326-0103
R49-R51 RES, THICK FILM, 1206, 0.25W, 1%, 240K 857326-0205
R4-R6, R10-R12 RES, THICK FILM, 1206, 0.25W, 1%, 1M 857326-0198
R56, R69-R71 RES, THICK FILM, 1206, 0.25W, 1%, 2.2 OHM 857326-0214
R58-R59, R121, R125 RES, THICK FILM, 0603, 0.1W, 1%, 1.5K 857326-0108
R60 RES, THICK FILM, 0603, 0.1W, 1%, 470 OHM 857326-0154
R62, R113 RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
857326-0186
R63, R86, R265 RES, THICK FILM, 0603, 0.1W, 1%, 4.7K 857326-0155
R7, R28, R90, R92, R96,
R107
RES, THICK FILM, 0805, 0.125W, 5%, 4.7
OHM
857326-0194
R73 RES, THICK FILM, 0603, 0.1W, 1%, 7.5K 857326-0175
R74 RES, THICK FILM, 1206, 0.25W, 1%, 680 OHM 857326-0210
R76-R77 RES, THICK FILM, 0603, 0.1W, 1%, 2.2K 857326-0127
R8, R27, R52 RES, THICK FILM, 0805, 0.125W, 1%, 22 OHM 857326-0189
R80, R82 RES, THICK FILM, 0603, 0.1W, 1%, 100 OHM 857326-0091
R84-R85, R88 RES, THICK FILM, 1206, 0.25W, 1%, 20K 857326-0200
R91, R139, R264 RES, THICK FILM, 0603, 0.1W, 1%, 3.3K 857326-0144
R93, R112 RES, THICK FILM, 0603, 0.1W, 1%, 1M 857326-0095
R94, R98, R110, R115 RES, THICK FILM, 1206, 0.25W, 1%, 220 OHM 857326-0203
R95, R135, R140-R142 RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R97, R108 RES, THICK FILM, 0805, 0.125W, 1%, 33 OHM 857326-0190
To Next Page
