Bose L1 Pro32 Service Manual

29
POWER-AMP PARTS LIST
Capacitors
Reference Designator Description Material Number Note
C101 CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
C132, C141, C225, C229,
C235, C258
CAP, X7R, 0402, 50V, 10%, 0.1uF, COMM 718866-104K1H
C213-C215, C222-C223,
C227
CAP, X7R, 0402, 100V, 10%, 2200pF, COMM 718866-222K2A
C216, C232 CAP, FILM, LS 5mm, AMMO, 5%, 100V, 1uF 329288-1004BJA
C217, C219, C231, C233 CAP, X7R, 0805, 100V, 20%, 0.01uF, COMM 763872-103M2A
C218, C230 CAP, C0G, 0805, 100V, 5%, 1000pF, COMM 763940-102J2A
C224, C226, C247, C249 CAP, X7R, 0402, 50V, 10%, 0.033uF, COMM 718866-333K1H
C228, C239 CAP, EL, SMT, 105C, 16V, 20%, 10uF, COMM 856752-
100M1CAB
C234, C238 CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C236-C237 CAP, X5R, 0402, 16V, 10%, 1uF, COMM 716994-105K1C
C26 CAP, FILM, PFC, 15mm, BULK 6mm, 630V,
10%, 1uF
856507-
105K2JBB
C261 CAP, X7R, 0402, 25V, 10%, 0.047uF, COMM 718866-473K1E
C275-C276, C278-C279 CAP, X7R, 0805, 100V, 10%, 0.1uF, COMM 763872-104K2A
C282-C283 CAP, X5R, 0603, 6.3V, 20%, 10uF, COMM 718835-106M0J
C29-C30 CAP, X7R, HI VOLT, 0805, 630V, 10%, 4700pF,
COM
852020-472K2J
C31 CAP, EL, SNAP-IN, 450V, 20%, 330uF 853707-
331M2WCC
C37-C38, C66-C67,
C81-C82, C98, C135-C140
CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
C40, C42-C43, C58-C59,
C61, C68, C91-C93, C95,
C108-C109
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C41, C85 CAP, C0G, 0603, 50V, 5%, 330pF, COMM 780788-331J1H
C45, C48-C51, C80 CAP, X7R, 0805, 25V, 10%, 1uF, COMM 763872-105K1E
C46 CAP, X7R, 0603, 100V, 10%, 220pF, COMM 718875-221K2A
C47, C69-C70, C75 CAP, X7R, HI V, 1206, 1000V, 10%, 4700pF,
COMM
852057-472K3A
C52-C53 CAP, EL, LOW Z, SMT, 35V, 20%, 470uF,
COMM
856727-
471M1VEF
C55 CAP, EL, POLYMER, SMT, 25V, 20%, 47uF,
COMM
857020-
470M1EAA
C60 CAP, X7R, 0603, 50V, 10%, 0.047uF, COMM 718875-473K1H
C62, C64-C65, C110-C111,
C113-C116, C284-C285
CAP, X7R, 0603, 100V, 10%, 0.1uF, COMM 718875-104K2A
C73 CAP, X7R, 0603, 50V, 10%, 1uF, COMM 718875-105K1H

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
