Bose L1 Pro32 Service Manual

30
POWER-AMP PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C76-C77 CAP, X7R, HI V, FT, 1210, 500V, 10%, 0.1uF,
COMM
852058-104K2H
C78 CAP, X7R, 0603, 50V, 10%, 0.47uF, COMM 718875-474K1H
C8, C17, C39, C97 CAP, X7R, 0603, 50V, 5%, 10000pF, COMM 718875-103J1H
C83, C100 CAP, C0G, 0805, 250V, 5%, 100pF, COMM 763940-101J2E
C84, C86 CAP, X7R, HI VOLT, 0805, 500V, 10%, 470pF,
COMM
852020-471K2H
C87-C88, C265-C266 CAP, EL, LOW Z, 18x25mm, 80V, 20%, 820uF 853760-821M1K-
GG
C89-C90, C267-C274 CAP, X7R, 0805, 100V, 10%, 0.47uF, COMM 763872-474K2A
C94 CAP, C0G, HI VOLT, 1206, 500V, 5%, 15pF,
COMM
777098-150J2H
C96 CAP, FILM, HI V, 15mm, BULK, 1000V, 5%,
0.68uF
856510-
683J3ABB
C99, C134 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
CN1 CONN, HDR, 3.96mm C, 2P, 1R, P, TH, ST,
WHITE
847743-0020
CX1-CX2 CAP, FILM, X2, LS 15mm, 305VAC, 20%,
0.47uF
310415-474MG 3
CY1-CY5 CAP, CER, X1/Y1, Bulk 25mm, 10%, 470pF 855444-471KG 3
CY6 CAP, CER, X1/Y1, Bulk 5mm, 20%, 1000pF 855444-102MN 3
Diodes
Reference Designator Description Material Number Note
BD1 DIODE BRIDGE, RECT., 15A, 600V 311087-0600
D11, D18-D22 DIODE, RECT, FAST, 1000V, 0.8A, RS1ML,
FLSMA
856386-1000
D14, ZD7-ZD10 DIODE, ZENER, 0.2W, 15V, 5%, SOD-323F 856094-15V0
D23, D26, D28, D34-D35 DIODE, SWITCHING, 100V, 0.15A, SOD323F 856395-0010
D6-D7 DIODE, SINGLE, 600V, 5A, RFNL58M6S, TO-
252
849891-0010
D8, D25, D27 DIODE, RECT, ULTRAFAST, 200V, 6A,
TPUH6D, SMPC
855862-0200
D9, D48 DIODE, RECT, FAST, 1000V, 1A 317066-1000
LED1-LED2 DIODE, LED, 0603, WHITE, VERT 851300-0010
ZD2-ZD4 DIODE, ZENER, 0.2W, 5.1V, 5%, SOD-323F 856094-05V1
