Setup
Connecting Power and a Sub1/Sub2
q
w e
tr
L1 Pro32Sub1/Sub2
1. Plug the SubMatch cable into the SubMatch Input on a Sub1/Sub2.
2. Plug the other end of the SubMatch cable into the SubMatch Output of the L1 Pro32.
3. Plug the power cord into the Power Input on the L1 Pro32.
4. Plug the other end of the power cord into a live electrical outlet.
Note: Do not power on the L1 Pro until after you've connected your sources. See Connecting Sources on
page9.
5. Press the Standby Button. The LED will illuminate white while the L1 Pro is on.
Note: Press and hold the Standby Button for 10 seconds to reset the L1 Pro to factory settings.
Press the Standby Button on any connected Sub1/Sub2. For additional information on how to set up a Sub1/
Sub2, see the Sub1/Sub2 owner's guide at PRO.BOSE.COM.
Note: When two Subs are connected to the L1 Pro32, first turn on the Sub connected directly to the L1 Pro32,
then turn on the second Sub.
AutoO/Low-power Standby
After four hours of no use, the L1 Pro will enter AutoO/Low-power Standby mode to save power. To wake
the L1 Pro from AutoO/Low-power Standby mode, press the Standby Button. When the L1 Pro32 goes into
AutoO/Low-power Standby mode, this will cut power to any Sub1/Sub2 connected with a SubMatch cable.
Press the Standby Button on a connected Sub1/Sub2 to wake it from AutoO/Low-power Standby mode.
Note: Disable AutoO/Low-power Standby mode by pressing and holding all three Channel Parameter
Controls for 10 seconds, or via the Settings page in the L1 Mix app. Enable AutoO/Low-power Standby mode
by repeating this step. Disabling AutoO/Low-power Standby mode will result in higher energy usage when
the L1 Pro is not in use.

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
