Bose L1 Pro32 User Manual

English • 9Owner's Guide • L1 Pro32 Portable Line Array
PRO.BOSE.COM
Setup
Connecting Sources
Channel 1 & 2 Controls
Channel 1 and 2 are for use with microphones, guitars, keyboards,
or other instruments. The channel inputs are suitable for a wide
range of input types and will have the proper gain staging to
minimize noise when the channel volume is set for the desired
output level.
1. Connect your sound source to the Channel Input with the
appropriate cable.
2. Apply a ToneMatch preset—to optimize the sound of your
microphone or instrument—by pressing the Channel ToneMatch
Button until the LED for your chosen preset is illuminated.
Use MIC for microphones and use INST for acoustic guitars
and other instruments. Use OFF if you do not want to apply a
preset.
Note: Use the L1 Mix app to choose custom presets from the
ToneMatch library. The corresponding LED will illuminate green
when a custom preset is selected.
3. Press the Channel Parameter Control to choose a parameter
to modify. The parameter name will illuminate white while it is
selected.
4. Rotate the Channel Parameter Control to adjust the level of the
selected parameter. The parameter LED will indicate the level of
the selected parameter.
Note: While Reverb is selected, press and hold the control for
two seconds to mute the reverb. While reverb is muted, Reverb
will flash white. To unmute reverb, press and hold for two
seconds while Reverb is selected. Reverb mute will reset when
the L1 Pro is powered o.
q w
e
r
INST

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
