Operation
Panel Operation
So that you will be better able to follow along with the instructions in this document, first press the ON/OFF pedal so that the
effects are “ON” (ON/OFF indicator is lit), and set the SELECT button to “MANUAL” (MANUAL indicator is lit).
Also, all knobs should be set as shown in the illustration.
* The AD-8 switches to “MANUAL” when the power is turned on.
fig.03-02
1.
Use the BODY TYPE knob to select the sound that
most closely corresponds to the basic, original
sound of the guitar you are using.
2.
Adjust the sound the body produces with the
BODY TYPE knob.
* Turn this knob to the left (counterclockwise) to get a sound
close to that of a guitar's own sound.
3.
Turn the STRING ENHANCE knob if you want
to bring out more of the pleasant overtones of the
guitar strings.
4.
Adjust the EQUALIZER knobs as necessary to
achieve the desired tone.
BASS:
This adjusts the balance of the lower range.
MIDDLE GAIN:
This adjusts the balance of the midrange.
MIDDLE FREQ:
This specifies the frequency band to be adjusted with the
MIDDLE GAIN knob. The band can be specified within
the range from 200 Hz to 1.6 kHz.
TREBLE:
This adjusts the balance of the upper range.
PRESENCE:
This adjusts the balance of the frequencies that are even
higher than those adjusted with the TREBLE knob.
5.
Add reverberation with the REVERB knob.
You can switch the knob to attain any of three different
reverb effects. The effect deepens as the knob is turned to
the right (clockwise).
AMBIENCE:
This provides a sense of distance in the sound, like that
obtained with off-mic recording.
ROOM:
This provides reverb like that obtained in a recording
studio.
HALL:
This provides reverb like that obtained in a concert hall.
6.
Adjust the volume with the OUTPUT LEVEL
knob.
1 2 3
4
56
