Physician Manual
91098825-02 60 of 337
Stimulator Physical Characteristics
The physical characteristics of the Stimulator are outlined in Table 1. The Stimulator
contains a radiopaque identication tag. The identication tag is visible using
standard x-ray procedures.
Table 1: Stimulator Physical Properties
Feature Description
Case Titanium
Header Epoxy
Dimensions 55 mm x 45 mm x 11 mm
Volume 20.7 cm
3
