Botex DMX DC-1224 User Manual

21 [HOLD]
Freezes all current DMX values at the output.
22 [STEP]
This button is used to advance to the next step when [SPEED] is at the lowest setting or when ‘Edit’ mode is acti-
vated.
23 [AUDIO]
Activates the ‘Audio’ mode.
24 [MASTER A]
Master fader for channels 1-12.
25 [MASTER B]
Master fader for channels 13-24.
26 [BLIND]
This key is used to temporarily remove individual channels from a running programme.
27 [HOME]
Use this key to end the Blind mode.
28 [TAP SYNC]
If the device is in ‘Run’ mode, you can manually set the operating speed with [TAP SYNC]. Hereto press the button
twice to set the speed.
29 [FULL ON]
Sets all DMX values to [255].
30 [BLACK OUT]
Sets all DMX values at the output to [000].
31 [FADE]
Use [FADE] to set the fade time.
32 [SPEED]
Use [SPEED] to set the Chase speed.
33 [AUDIO LEVEL]
Use [AUDIO LEVEL] to set the audio sensitivity.
34 [FOG MACHINE]
Operating and display elements for a fog machine.
Connections and controls
14
DMX DC-1224
DMX controller
