7. Keep [RECORD] pressed and additionally press one of the [FLASH] buttons
between 13 and 24
ð
All record LEDs flash once.
The program is saved.
8. To exit programming mode, press [Exit] and [RECORD] simultaneously.
Programming a chase with 16 steps with channels 1-16 and storing a sequence to
[Flash 15] on Page 1.
1.
Activate the programming
Ä
Chapter 7.1.1 ‘Enabling programming’ on page 16.
Make sure the faders [Master A&B] are both set to their maximum.
[MASTER A] is set to maximum when it is at the top. [MASTER B] is set to
maximum when it is at the bottom).
2. To select the mode ‘1-24 Single’, press [MODE SELECT]. This gives you control
over all 24 channels.
3. Slide channel fader 1 to position 10.
ð
The LED lights up fully.
4. To save the desired scene as a step, press [RECORD].
5. Repeat steps 4 and 5 until all channels 1-16 have been programmed.
6. Press [PAGE] until the LED at [PAGE 1] is lit.
7. Press [FLASH 15] while holding down [RECORD] .
ð
All record LEDs flash once.
The program is saved.
7.2 Editing
7.2.1 Programme editing
1.
Activate the programming (
Ä
Chapter 7.1.1 ‘Enabling programming’
on page 16).
2. Use [PAGE] to select the page where the programme to be edited is stored.
3.
Press [MODE SELECT] to select [CHNS
〈
〉
SCENES] .
4. Keep [EDIT] pressed.
5. Press the respective [FLASH] button.
6. Release [EDIT] .
ð
The LED of the corresponding scene lights up, indicating that the device is
in ‘Edit’ mode.
Example programme
Operating
18
DMX DC-1224
DMX controller
