n The controller sends and receives Note On and Note Off data via the [Flash] but-
tons.
Note No. Touch velocity Functions
22-69 Programme master Turns programmes 1-48
on or off.
70-93 Channel intensity Activates channel 1-24.
94 Full on
95 Dark
96 Hold
97 Turns audio on or off.
98
CHNS〈 〉SCENES
99 ‘Double Preset’ mode
100 ‘Single Preset’ mode
101 Step
102 Black out
8.2 DMX
8.2.1 DMX channel settings
1.
Activate the programming (
Ä
Chapter 7.1.1 ‘Enabling programming’
on page 16).
2. Keep [RECORD] pressed.
3. Press [FLASH 8] three times.
ð
The display shows the current DMX channel.
4. Use [UP] and [DOWN] to select a DMX channel between 1-512.
5. Then press the desired [FLASH] button between 1-24.
ð
The selected DMX channel is assigned to the console
6. If you press [FULL ON] the highest value ‘255’ will be output in the current DMX
channel.
ð
All [FLASH] LEDs light up.
7. If you press [BLACK OUT] the lowest value ‘000’ will be output in the current
DMX channel.
ð
All [FLASH] LEDs turn off.
8. To quit the Setup mode, keep [RECORD] pressed and additionally press [EXIT].
MIDI and DMX channel settings
DMX DC-1224
25
DMX controller
