15
M12/M15/M18
4 Technical Specifications 4
Machine
Heating
M15
Steam
M15
Electric
Filling quantity kg (lb) 15 (33.1) 15 (33.1)
Cage volume l (US gal) 300 (79.2) 300 (79.2)
Cage diameter mm (in) 820 (32.3) 820 (32.3)
Cage depth mm (in) 570 (22.4) 570 (22.4)
Load diameter mm (in) 400 (15.7) 400 (15.7)
Cleaning speed/drying speed RPM 35 35
Spinning speed: RPM 600 600
Max. g-factor. 165 165
Low level l (US gal) 35 (9.2) 35 (9.2)
High level l (US gal) 75 (19.8) 75 (19.8)
Operating load (max. at 400 V, 50 Hz)
Without distillation kW 7 16
With distillation kW 8 27
Connected loads:
Compressor capacity kW 4.0 4.0
Fan capacity HLL /NLL kW 2.5 /1.85 2.5 /1.85
Solvent pump capacity kW 1.1 1.1
Cage drive capacity kW 3.7 3.7
Filter drive capacity kW 0.55 0.55
Vacuum pump capacity kW 0.37 0.37
Steam generator capacity Distill. /drying kW - 10 /8.5
Dimensions:
Machine:
Width: Slimline
Crossline
mm(in)
mm(in)
1080(42.5)
1840(77.4)
1080(42.5)
1840(77.4)
Depth: Slimline
Crossline
mm(in)
mm(in)
2165(86.0)
1406(55.3)
2165(86.0)
1406(55.3)
Height inc. trough mm(in) 2257(89.0) 2257(89.0)
Height inc. trough without fan motor mm(in) 1995(78.5) 1995(78.5)
Floor space: Slimline
Crossline
m
2
(ft
2
)
m
2
(ft
2
)
2.3(24.8)
2.5(26.9)
2.3(24.8)
2.5(26.9)
Filling volumes:
Tank I filling l/ US gal 145 (38.3) 145 (38.3)
Tank II filling l/ US gal 95 25.1) 95 (25.1)
Tank III filling l/ US gal 90 (23.7) 90 (23.7)
Economy filter 1 l/ US gal 40 (10.6) 40 (10.6)
Economy filter 2 l/ US gal 40 (10.6) 40 (10.6)
Distillation filling l/ US gal 120 (31.7) 120 (31.7)
Cartridge filter l/ US gal 15 (4) 15 (4)
Jumbo Cartridge Filter l /US gal 40 (10.5) 40 (10.5)
The dimensions given may differ if special options are used
