Bowflex Max Total 16/40 - Page 34

34
If the Rollers seem to be “off” and not fully tracked on the Rail Assembly,
this procedure may assist.
1. Unplug the AC Power Adapter from the machine.
2.Usinga#2Phillipsscrewdriver,removethe1indicatedscrewfromthe
Rear Shroud.
3. Carefully remove the Rear Shroud from the machine. Place a standard
screwdriver behind and near the middle of the Rear Shroud and gently pry
until it just releases. Then move the screwdriver to the bottom and gently
pry until the Rear Shroud comes off.
Rear Shroud
Rail Assembly
Roller riding
slightly outward
or “off” of the Rail
Assembly
