35
4.Usinga6mmhexwrench,slightlyloosentheindicatedboltsthatsecurethe
Rail Assembly to the Frame Assembly.
Do not fully remove the hardware.
5. Using a 8mm hex wrench, slightly loosen the indicated bolts that secure the
Rail Assembly to the Base Assembly.
Do not fully remove the hardware.
6. Shift the Rail Assembly back and forth, or “wiggle”, until it seems to settle
intothecorrectconguration.TheRollerswillhaveadjustedwiththeRailAs-
sembly, and should be more “on” with the groove of the Roller centered onto
the Rail Assembly.
7. Installation is the reverse procedure.
8. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are
properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
Rail Assembly
