8. Dispose of the removed piece of White Wire.
9. Re-assemble the machine in the reverse order of when the parts were removed.
Note: DonotcutorcrimptheCables.EachCableconnector(3-pin,4-pin,5-pinand14-pin)hasacor-
responding end connector with that many openings. Be sure to fully connect the cable connectors. When
attaching the Console Assembly, do not fully tighten the hardware until all hardware has been hand
tightened.
10. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s
Manual.
