Bowflex Max Total 16/40 - Page 60

60
13.Usinga9/16”or14mmsocketandwrench,removetheindicatednutfrom
the Crank Assembly.
14.AdjusttheCrankPulleruntiltheendoftheBoltisinsidetheNut(as
shown).
15. Carefully thread the Crank Puller into the Crank Arm. Be sure the Crank
Puller has at least three rounds of threads inserted.
16. Using an adjustable wrench, turn the inner portion (the Bolt) of the Crank
Puller clockwise. The Crank Arm Assembly will slide off as it is tightened.
Note: Be aware that the Crank Arm Assembly will be loose and will need to be
supported.
Bolt
Nut
