Bowflex Max Total 16/40 - Page 75

75
1. Unplug the AC Adapter from the wall outlet and machine.
2. Using a 5mm hex wrench, remove the indicated hardware from the Left
Upper Handlebar and place it out of the work area.
Note: Be aware that the Upper Handlebar must be supported when
removing the hardware.
3.Usinga#2Phillipsscrewdriver,removethe4screws(2indicatedon
one side) from the Upper Shroud and remove it.
4.RemovetheindicatedCapfromthemachine.
5. Using a 6mm hex wrench, remove the hardware exposed from below
the Cap.
6. Slide the Left Leg Assembly off of the machine.
Upper Shroud
Left Upper
Handlebar
Leg Assembly
Cap
