9. Using a 5mm hex wrench, remove the screws (indicated by ovals) from
the Static Handlebar Assembly.
10. Carefully lift the Static Handlebar Assembly and expose the Cable
Connections.
Note: Do not crimp any of the Console Cables. This step may require two
people.
11. Carefully disconnect the Cables while not allowing them to fall into the
Console Mast.
Note: Do not crimp any of the Console Cables.
12. Using an 8mm hex wrench, remove the indicated hardware from the
Rail Assembly.
Static Handlebar
Assembly
To Next Page
