Bowflex Max Trainer M3 - Parts Identification

Assembly / Owner’s Manual
7
A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Item Qty Description Item Qty Description
1 1 Frame 10 2 Pedal
2 1 Shroud, Rear 11 1 Rail Assembly
3 1 AC Adapter 12 1 Stabilizer Assembly
4 1 Hardware Card 13 1 Static Handlebar Assembly
5 1 Upper Handlebar, Right 14 2 Cap
 1 Upper Handlebar, Left 15 1 Static Handlebar Grip
7 2 Leg  1 Static Handlebar Cap
8 2 Foot Pad 17 1 Heart Rate Chest Strap
9 2 Foot Pad Insert 18 1 Manual Kit
5
11
7
12
9
6
7
8
9
8
10
10
13
14
17
15
16
18
1
3
2
4
Parts
