Cable Installation STEP 2
a. InBox4LocateaFloatingPulleyAssemblyanda
SinglePulleyAssemblywithtwoCheeks.
(See Figure A)
b. FeedthecablethroughtheFloatingPulleyAssembly.
(See Figure B)
c. RoutethecablebehindtheSidePlateandwrapover
theSinglePulleyAssembly.(See Figure C)
d. InstallSinglePulleywithcableonthebacksideof
theLatTowerasshown.(See Figure D)
Figure A
Route Cable Through
Floating Pulley Assembly
Figure B
Route Cable Through
Behind Side Plate
Wrap Cable Over
Single Pulley Assembly
Pan Head Al-
len Bolt
Washer
Tool:
 •HexKey(7/32”)
Figure C
Figure D
(Rod Pack Removed For Clarity)
Installing Your Bowflex Ultimate
®
2 Cables
Floating Pulley Assembly Single Pulley Assembly
Cheeks
Button Head Screw
Washer
Pulley
