BOXER 322D - Page 28

Pre Start Inspection and Operation
3.5
Figure 3-3 Fuel Level Check
• Carefully pour the fuel into the tank, not exceeding the “F”- Full indicator on the fuel
gauge.
• Allow engine to cool before lling fuel tank.
• Do not overll because fuel could spill onto hot engine parts and ignite or
explode.
4. Check engine coolant level.
The coolant is hot and under pressure. DO NOT check until the engine radiator is cool
to the touch.
• When the radiator is cool to the touch, remove the radiator cap (Item 1, Figure 3–4) and
check the radiator uid level. The proper coolant level will be to the bottom of ller
neck. (Item 2, Figure 3–4).
• The overow bottle is a non-pressurized container that is only for any high heat
overow. Do not add coolant to this container. It will not be drawn into the engine.
• If coolant is required, make sure to add the proper coolant as shown in the Engine
Manual.
1
E
F
2
CAUTION
CAUTION
NOTICE
