BPW ECO Plus - Page 8

Tightening torques
11
Description Thread Tightening torque
Hub caps
according to stamped tightening torque
on face of cap
BPW form Caps for ECO
Plus
hub 8  12 t
Caps for ECO hub 6.5  14 t
Steel caps 6  12 t
Steel caps 13  20 t
Alloy caps 6  12 t
Lock nuts of wheel studs (brake drum side)
with 6 steel studs (wheel side M 18 x 1.5)
Lock nuts on hexagon screws (Trilex wheels)
Axle nut
Wheel nuts
Lock nut for slack adjuster
Locking screws on cover plates
Selftapping screw for sensor holder
Hexagon screws on bearing box (Tensilock)
Hexagon screws on bearing box
M 20 x 1.5
M 20 x 1.5
M 22 x 2
M 20  8.8
M 20  10.9
M 22 x 1.5
M 10
M 8
M 8
M 8
800 Nm
800 Nm
500 Nm
700 Nm
350 Nm
355 Nm (340  370 Nm)
495 Nm (470  520 Nm)
640 Nm (610  670 Nm)
335 Nm (320  350 Nm)
450 Nm (430  470 Nm)
see pages 34 to 36
see page 37
80  90 Nm
43 Nm
25 Nm
28 Nm
23 Nm
