Lesson 2: Adding Graphics to Labels
Clear a Label and Return Home
Lesson 2: Adding Graphics to Labels
1. From the Home page, touch anywhere in the Editor.
2. Select Graphic . The box on the left shows the available graphic
categories. As you touch a category, the available graphics for that category
will display in the box on the right.
3. In the Category list, use the up or down arrows to scroll to the
Warning category.
4. Select any of the available graphics to add it to your label. The graphic size is
maximized to fit the entire width of the installed tape.
5. To resize the graphic, use the Size or just like text.
To set a specific graphic size:
1. Touch the graphic.
2. Touch the right arrow of More Options .
3. Select Exact Size & Position .
4. In the Object width field, enter
2.
5. Select OK . The graphic width is sized proportionally to
2 in. [50.8 mm].
