Operations
Load Media
36
Y882746 BBP81 User Manual 5/13/08
4. Feed the media under the dancer assembly (1), the upper media sensor (2), the ribbon
sensor (
3), and the adjustable sensor (4). (See Step 5 for sensor location of media type.)
Slide the media back until it touches the inside back wall of the upper media sensor.
b. Place the roll of media on the media
supply spindle. Push the roll as far
back as it will go.
OR
PermaSleeve Material Only
b. Drape the media over the media
supply spindle.
Roll Media (Continued)
Fanfold Media (Continued)
To Next Page
