1 Introduction
Use the Brady Express Labels mobile app or Brady Workstation software to design labels and print to
the M511 label printer. The M511 printer includes the following features:
• Withstands a 6 ft. (1.8 m) drop
• Crush resistant to 250 lbs (113.4 kg)
• Military-grade shock resistance
• Uses M50 series print cartridges
• Automatic label cutter
• Connect up to five simultaneous users with Bluetooth® Low Energy 5.0
• Compact and lightweight at 2.3 lbs (1.06 kg)
• Prints 1000 labels per day
• Internal lithium ion battery
• USB-C to USB-A coupler
System Specifications
The M511 printer has the following specifications:
• Weight 2.77 lbs (1.26 kg) (with label cartridge)
• Thermal transfer print mechanism, 300 dpi
• Print width: 1 - 1.44" (25.4 - 36.6 mm)
• Print length for labels: 39” (990.6 mm) maximum
• Liner width: 1.8" (46 mm) maximum
• Label widths from 0.235" (6.0 mm) through 1.5" (38.1 mm)
• Minimum label height: 0.236" (5.99 mm)
• Prints up to 300 labels per battery charge
• Print speed: up to 1.33 in/sec (33 mm/sec)
• Internal lithium ion battery, 2450 mAh
