Braeburn 1000NC - Room Temperature; Arrow Buttons; System Switch; Backlight Button

1
5 Setting User Options
6
Operating Your Thermostat
7 Additional Operation Features
8 Thermostat Maintenance
For installation by experienced service
technicians only. Follow applicable codes.
2
About Your Thermostat
3
Installation
Warning
Disconnect power before beginning installation.
Thermostat Location
Installthethermostatapproximately4-5feet(1.5m)abovetheoorinan
areathathasagoodamountofaircirculationandmaintainsanaverage
roomtemperature.
Avoidinstallationinlocationswherethethermostatcanbeaffectedby
drafts,deadairspots,hotorcoldairducts,sunlight,appliances,concealed
pipes,chimneysandoutsidewalls.
2
3
4
5
8
7
9
6
1
Room Temperature........... Displaysthecurrentroomtemperature
Arrow Buttons.................. Usedtoincreaseordecreasesettings
System Switch..................SelectsHeat,CoolorOff
Backlight Button..............Illuminatesthedisplaybacklight
Low Battery Indicator...... Indicateswhenthebatteriesneedto
  bereplaced
System Status Indicator...Displaysinformationaboutthestatusof
   thesystem
Reset Button..................... Resetsthermostatbacktofactorydefaults
Fan Switch........................Selectsthesystemfanmode
Battery Compartment....... Locatedinthebackofthethermostat
1
2
3
4
5
6
7
8
9
