Brähler Systems DIGIMIC DCen mini - Microphone Units Pro Series

DCen mini DIGIMIC®
18 Copyright by BRÄHLER ICS AG
Microphone units Pro Series
DCEN mini also works with the microphone units of the DIGIMIC Pro Series. With access to a LAN and the
PC software DMicControl, all connected microphones can be controlled. Using this software more
microphone modes such as MAN (manual control) are available.
DMicDMic
DChair
DCen mini
Switch /
Hub
PC Software
• DMicControl
DMic
100 – 240 VAC
Power Supply
Adapter cable
08.3502
D9 cable
LAN cable
D9 cable
D9 cable
Expansion with additional power supply
With a DExt (additional power supply), a discussion system with classic units can be extended. To do so
adapter cables are required.
CMic CSV
DCen mini
CMic CSV CMic CSV
CChair CSV
CMic CSV CMic CSV CMic CSV
DExt
90 – 240 VAC
50 – 60 Hz
100 – 240 VAC
Power Supply
Adapter cable
08.3500
Adapter cable
08.3502
In conjunction with microphone units of the Pro Series there is only the adapter cable for the direct
connection (08.3502) to DCEN mini necassary.
Up to 100 delegates units including 3
power supplies DExt are possible
