Analog input card ( part number AI183V )
AI183V are analog input cards in 1, 2, 3 channels respectively. Each card includes linear input of ± 60mV,
± 20mA, ± 2V, and ± 20V only. To select a specific input, first set jumpers and switches according to the
sticker information on the card as Figure 2–16, and plug it into the rear slot then power on. The recorder
will automatically detect the card and display the specific input type, then show its source of a specific slot
in Configuration Mode. All inputs were initially set for -20mA~20mA from the factory.
Figure 2 – 16
Digital Output card ( DO181 ) / 6 relay alarm card
The digital output card includes 6 relays rated 5 Amp/240 VAC. Plug the card into rear slot and power on.
The recorder will automatically detect the card and then display the output type and its source of a specific
slot in System Info mode whilst doing the configuration. To set up the digital output card, please refer to
Event, Job of 4.1 Channel.
Digital Input card ( DI181 )
This card includes 6 channels of event 1, 2, 3, 4, 5 & 6. As above, plug the card into rear slot and power on.
The recorder will automatically detect it, and then display the input type and its source of a specific slot in
System Info mode whilst doing the configuration.
Analog output cards ( AO183I, AO183V )
These two cards are 3-channel current output card AO183I, and 3-channel voltage output card AO183V.
They are used to retransmit process value to another device.
24 VDC auxiliary power supply card ( AP181 )
This card can supply the power to 6 transmitters. The output rating is 24 ± 1 VDC, 180 mA in maximum,
30mA / each transmitter.
