Branson 2100 - Tightening Torque

REAR AXLE
KUKJE MACHINERY CO., LTD.
106
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
Item N·m kgf·m ft-lbs
Rear wheel bolt and nut 108.0 to 125.0 11.0 to 12.7 79.0 to 92.2
Rear axle case mounting screw 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
