ELECTRIC SYSTEM
KUKJE MACHINERY CO., LTD.
161
Refer to Workshop manual for Diesel Engine Mechanism and Tractor Mechanism as following terms.
[1] ENGINE STARTING SYSTEM AND STOPPING SYSTEM
(1) Main Switch : [Type 1] in Workshop Manual for Tractor Mechanism.
(2) Starter Motor(MT) : [Electromagnetic Drive Type] in Workshop Manual for Engine Mechanism.
(3) Starter Motor(HST) : [Planetary Gear Reduction Type] in Workshop Manual for Engine Mechanism.
(4) Starter Relay(MT) : Workshop Manual for Tractor Mechanism.
(5) Glow Plug :[Quick Glow System] in Workshop Manual for Engine Mechanism.
(6) Key Stop Relay(HST) : This part is the same as the above-mentioned “(4) Starter Relay”.
(7) Engine Stop Solenoid(MT) : [Energized-to-stop] in Workshop Manual for Engine Mechanism.
(8) Engine Stop Solenoid(HST) : [Energized-to-run Type] in Workshop Manual for Engine Mechanism.
[2] CHARGING SYSTEM
(1) AC dynamo : Workshop Manual for Engine Mechanism.
(2) Regulator : [Regulator for AC dynamo] in Workshop Manual for Engine Mechanism.
[3] LIGHTING SYSTEM
(1) Combination Switch : [Type1] in Workshop Manual for Tractor Mechanism.
(2) Hazard Switch : Workshop Manual for Tractor Mechanism.
[4] EASY CHECKER
(1) Engine Oil Pressure Switch : [Type1] in Workshop Manual for Tractor Mechanism.
[5] GAUGES
(1) Fuel Level Sensor : [Type1] in Workshop Manual for Tractor mechanism.
(2) Coolant Temperature Sensor : Refer to Workshop Manual for Tractor Mechanism.
6. OTHERS
