2.3.11. Trip Status of Monitors
Each Monitor reflects its trip status via the Test Interface as a logic signal to the periphery.
Output high: no trip
Output low: trip
Note:
The outputs have a delay of approx. 10 seconds versus the trip of the monitor.
The Outputs "Trip Status of Monitor" are rated SIL2/IEC61508.
Technical Data of output see 3.2.4
