9. This chapter is left blank intentionally
10. Event codes and Troubleshooting
10.1. Event Codes on display of E1665
The Event Codes are shown in format E.0.x.x.x .
Depending on setting of P02.11 only the first occurred fault or all faults are displayed (combi-
nation of faults is possible).
Display
Explanation of Event Code
E.0.0.0.0
Overspeed trip (if P03.02 = 0)
E.0.x.x.1
Sensor failure (current or voltage), refer to P02.05
E.0.x.x.2
Deviation of primary sensor versus neighbor sensors, refer to P02.07
E.0.x.x.3
E.x.x.x.1 + E.x.x.x.2
E.0.x.x.4
Speed < SP2
E.0.x.x.5
E.x.x.x.1 + E.x.x.x.4
E.0.x.x.6
E.x.x.x.2 + E.x.x.x.4
E.0.x.x.7
E.x.x.x.1 + E.x.x.x.2 + E.x.x.x.4
E.0.x.1.x
Generator tests with zero speed
E.0.x.2.x
Trip by Voter
E.0.x.4.x
Internal relay fault
E.0.1.x.x
Failure detection during internal self test
E.0.2.x.x
Overspeed trip (if P03.02 = 1)
E.0.3.x.x
E.x.1.x.x + E.x.2.x.x
E.0.4.0.0
Alarm caused by missing external signals (Trip-Lines)
(for troubleshooting refer to next page)
E.0.4.2.0
Trip by voter ( with non-coincidence at inputs of voter)
E.0.6.x.x
E.x.2.x.x + E.x.4.x.x
E.0.8.0.0
Trip-Line Monitoring has caused trip
E.0.A.0.0
Trip due to Overspeed (and P07.00 = 1 or 3)
E.0.c.0.0
Trip-Line Monitoring has caused trip plus antivalence of signals for Trip-Line-Monitoring
(for troubleshooting refer to next page)
E.3.0.1.0
Starter Input is active at speed > 50% of SP1A (only if P02.06 = 1 or 2)
E.3.0.2.0
External Analog output error ( 'no load' or fault of connected device )
E.3.0.2.1
Internal Analog output error (fault on monitor board)
-E1-
Wrong code figure in step P00.00
