Braun E16x442 - Dimensions of the E16 A442 System

I E16x442 Rev: 00 Page 28 of 73
3.8. Dimensions of system E16A442
Figure 9: Dimensions of System E16A442
front view
Height incl. backplane + terminals
all dimensions in mm
Drawing not to scale
wiring from
top and bottom
Ø 13
88
220
201.5
109.3
21.3
21
133
195
20
6.4
Detail
Mounting holes
to hang the racks to
premounted screws
total depth (incl. Profibus plug with 35° cable outlet)
wiring
side view
wiring
premounted screws or
bolts with nuts
pluggable
terminal
blocks
265
220
