Display E.0.4.x.x signalizes a fault (not all signals are identical) from the input signals for the
voters or for Trip-Line-Monitoring (resp. feedbacks from 2oo3-solenoid).
The actual status of the signal inputs is shown in Special Display Mode 2.
Switching between Standard and Special Display Mode 2 by pressing keys and to-
gether.
Special Display Mode 2
In Special Display Mode 2 LED1 and LED4 are blinking.
Steps of Special Display Mode 2 : 0._x.x.x
1._x.x.x
2._x.x.x
3._x.x.x
4._x.x.x
Steps of Special Display Mode 2 are selected with key (next step) resp.
key (previous step).
For troubleshooting only steps 3. _x.x.x and 4. _x.x.x are relevant.
The status of signal inputs for Trip-Line-Monitoring are shown in step 3 .
Display of:
3._x.x.1 : Feedback signal from Trip-Line I is true
3._x.x.2 : Feedback signal from Trip-Line II is true
3._x.x.4 : Feedback signal from Trip-Line III is true
resp. all combinations hereof, for example:
3._x.x.7 : all Feedback signal from Trip-Lines are true
The voter signal inputs are shown in step 4._x.x.x
Display of:
4.n.0.0.1 : Voter n, input 1 active n = 1 - 6 (7 reserved)
4.n.0.0.2 : Voter n, input 2 active
4.n.0.0.4 : Voter n, input 3 active
resp. all combinations hereof, for example:
4.3.0.0.5 : Voter 3, inputs 1 und 3 active, input 2 not active.
While key is pressed, the input status latched at error will be shown, else the current in-
put status.
Switch the input status of voter 1 to 6 with key
.
