I E16x442 Rev: 00 Page 4 of 73
Figure 1: E16x442 System Front View 1
Figure 2: E16x442 System Structure Diagram 1 of 2 11
Figure 3: E16x442 System Structure Diagram 2 of 2 12
Figure 4: E16x442 System Wiring Diagram 1 of 3 13
Figure 5: E16x442 System Wiring Diagram 2 of 3 14
Figure 6: E16x442 System Wiring Diagram 3 of 3 15
Figure 7: Position of terminal blocks with version E16E442 16
Figure 8: Position of terminal blocks with version E16A442 17
Figure 9: Dimensions of System E16A442 28
Figure 10: Dimensions of System E16E442 29
Figure 11: Dimensions of E16G442 Enclosure 30
Figure 12: Front view of Monitor E1665 32
Figure 13: SP1 as a variable of the acceleration 51
