Driving and Operating 149
Charge Port Light Color Sound Action/Reason
Solid Blue One audible chirp Initial connection is successful.
Pulsing Blue Two audible chirps Charging is delayed by charging screen or by a total
utility interruption. Charging will begin later. See
Utility Interruption of Charging 0 150.
Blinking Green (the longer
the blink, the higher the
state of charge)
Two audible chirps Vehicle is actively charging.
Solid Green None Charging is complete.
Blinking Red None There is a charging error.
Check the charge cord connection. There may be no
power supplied to the vehicle.
Blinking Green Four audible chirps There is not enough time to fully charge the vehicle
by the selected departure time.
Perform a delayed charging override to increase the
battery charging speed. See Delayed Charging
Override 0 148.
None (upon plug-in) None Check the charge cord connection.
