Vehicle Care 167
The vehicle may not be equipped with all of
the fuses, relays, and features shown.
Fuses Usage
F01
ICCM – Integrated Chassis
Control Module
F02 Short Range Radars
F03 –
F04 –
F05 –
F06 Coolant Valve
F07
ESSCP – Energy Storage
System Coolant Pump
F08 –
F09
PECP – Power Electronics
Coolant Pump
F10
–
PCV/SCV/PEEV – Primary
Coolant Valve/Secondary
Coolant Valve/Primary
Evaporator Expansion Valve
F11 –
F12 –
F13 –
Fuses Usage
F14 –
F15
ACL/LRR – Ambient Color
Lamp/Long Range Radar
F16 –
F17 –
F18 Front Heated Seats
F19 –
F20 –
F21 –
F22
ECFV/CHFV/AERO SH –
External Condensor Flow
Valve/Condensing Heating
Flow Valve Motor/
Aeroshutter
F23
VECM/Spare – Vehicle
Integrated Control Module/
Vehicle Extension Control
Module/Spare
F24 –
F25 –
F26 –
Fuses Usage
F27
PCV/SCV/PEEV – Primary
Coolant Valve/Secondary
Coolant Valve/Primary
Evaporator Expansion Valve
–
F28 –
F29 Spare
F30
TRANS OIL PUMP –
Transmission Oil Pump
F31 –
F32 –
F33 –
F34 –
F35 Spare
F36
TPIM 3 – Traction Power
Inverter Module 3
F37 –
F38 –
F39 Rear Door Latch
F40 –
F41 –
