Brivis BX3C User Manual

Rinnai 15 Ducted Gas Heater IM
3.4 ORIENTATION OF FLUE TERMINAL
The flue terminal for BX3C models is supplied and fitted to the heater as shown in Diagram 2 The flue terminal must
be orientated correctly to ensure flue gases are expelled away from the building wall as shown.
Diagram 2.
NOTE
Open area of ue terminal MUST be discharging away from building
FLASHING
WALL
LEVEL
CONCRETE
OPEN AREA OF
FLUE TERMINAL
BASE
GROUND
HEATER DIMENSIONS AND CLEARANCES

Brivis BX3C Specifications

General

Brand	Brivis
Model	BX3C
Category	Gas Heater
Language	English
