Rinnai 9 Ducted Gas Heater IM
2. GENERAL PRODUCT GUIDELINES
2.1 APPLICATION AND SIZING
These Classic heaters are designed to provide a central source of heat for a ducted central heating system.
The heaters should not be installed downstream from an air washer, an evaporative cooler or refrigerative cooling
system. Nor are they designed to be installed on a marine craft, houseboat, or any similar environment.
The Classic heaters must be installed in accordance with these instructions and related regulations, codes,
standards, and authorities. These include but may not be limited to:
• AS/NZS 3000 - Electrical Installations
• AS/NZS 5601 - Gas Installations
• AS 4254 - Ductwork for air-handling systems in buildings
• HB 276 - A Guide to Good Practice
• AS/NZS 5141 - Residential Climate Control Systems
• Local Gas and Electricity Authority Codes
• Brivis “SuperSizeGuide”/Brivisize™
• Product Sizing Guide
• Local Building Regulations
• Environment Authorities
• National Construction Code of Australia (NCC)
Brivis assumes no responsibility for equipment installed in violation of any code, regulations and these
installation instructions.
It is recommended the Brivis "SuperSizeGuide"/Brivisize™ be followed in estimating heating requirements and for
system design that will result in efficient installation and provide a higher level of comfort and economical operation.
For the hourly input and the gas type to be used, see the appliance data label located inside the service compartment.
All installations should only be carried out by a qualied tradesperson. Installations at altitudes
greater than 1000m above sea level may require upgrading of main burner injectors. Please
contact the Customer Service Centre for advice.
It is recommended the Product Sizing Guide is followed in estimating heating requirements and for system design
that will result in efficient installation and provide a higher level of comfort and economical operation.
For the hourly input and the gas type to be used, refer to the appliance data label located inside the service
compartment or the Technical Specifications at the back of this manual.
2.2 INSPECTION
This appliance has been inspected and tested at the time of manufacture and packaging and released for
transportation without known damage. Upon receipt, inspect the exterior for evidence of rough handling in shipment.
Ensure that the appliance is labelled correctly for the gas to which it is intended to be connected. If a discrepancy or
damage to the appliance is identified DO NOT install the appliance and report findings back to supplier.
2.3 UNPACKING THE HEATER
Some heaters are supplied on a pallet with a plastic sleeve. To unpack:
• Cut and remove the external plastic packaging and dispose of thoughtfully.
• Remove heater from pallet (if supplied).
Some heaters are supplied with a base box assembly wrapped with a removable plastic film to protect the surface.
ALWAYS remove and dispose of the plastic lm before mounting the heater onto the base box.
2.4 UNLOADING OR LIFTING THE HEATER
When unloading or lifting the heater, ensure lifting equipment is in good operating condition and capable of lifting
the total load. Be sure there is a clear area to place the heater down, which is within reach of the lifting equipment.
DO NOT use the lifting handles provided to lift the heater above head height. If tting the heater
to elevated heights such as a roof, use suitable lifting equipment.
