Rinnai 25
Ducted Gas Heater IM
Diagram 8.
BX3C Thermostat Connection
Diagram 9.
2PWN Thermostat Connection
W & R
T
erminal
Block
W
R
T/ST
A
T
Field Supplied
T
win-core, ‘Figure 8’
0.75mm
2
Cable
2PWN Illustrated
THERMOST
A
T INST
ALLA
TION
W & R
T
erminal
Block
Grommet
W
R
T/ST
A
T
Field Supplied
T
win-core, ‘Figure 8’
0.75mm
2
Cable
24
