Brivo ACS5000 - Wiring Recommendations; Additional Resources

ACS5000 Installation Manual Page 5
© 2017 Brivo Systems LLC. All rights reserved. Rev 1
Wiring Recommendations
Signal
Belden # or
Equivalent
AWG
Twisted
Pair
Conductor
Shielded?
Max
Length
Power (22 gauge)
5504FE
22
Yes
Yes
600 ft
Power (18 gauge)
6300FE
18
Yes
Yes
1500 ft
RJ45-Ethernet (CAN Bus)
N/A
Cat5
Yes
Yes
1500 ft
Fire Alarm Relay
6300FE
18
Yes
Yes
1500 ft
Request-to-Exit
5520FE/6300FE
22/18
Yes
Yes
1500 ft
Door Contact
5500FE
22
Yes
Yes
1500 ft
Transformer Block
6300FE
18
Yes
Yes
1500 ft
Molex Connector
N/A
22
Yes
No
1 ft
Earth ground
N/A
6
Yes
Yes
20 to 40 ft
Reader Data 1
5504FE
22
Yes
Yes
250 ft
Reader Data 2
5400FE
20
Yes
Yes
300 ft
Reader Data 3
6300FE
18
Yes
Yes
500 ft
Additional Resources
The following additional resources are available for the installer as well as the client.
• Networking Admin Interface Guide
• Reader/Keypad Wiring Guide
• Installation Worksheet: Network
• Installation Worksheet: Door Board
• Installation Worksheet: Input Output Board
• Brivo OnAir Quick Start Guide
• Brivo Cellular Network Router Configuration Guide
• Brivo OnSite Quick Start Guide
• Brivo OnSite Server Quick Start Guide
• Technical Support: 1-866-BRIVO-4-U
• www.brivo.com
