ES-2200T Configuration Options
It is possible to install a single card – TBC, MicroSYNC, V-Scope or Routing Switcher in the ES-2200T chassis. In
such a case, the card should be installed in the Unit 1 position unless it is a V-Scope. If it is a V-Scope, it should
always go in the Unit 2 position. Two cards can be installed in the ES-2200T chassis. The possible configurations are
as follows:
Unit 1 Unit 2
TBC TBC
TBC V-Scope
TBC Routing Switcher
TBC 8-Bit MicroSYNC
8-Bit MicroSYNC TBC
8-Bit MicroSYNC V-Scope
V-Scope V-Scope
Routing Switcher Routing Switcher
If you put only one card in the ES-2200T chassis, unless it is a V-Scope, place it in Unit 1 position. If you are putting
one of the above cards in the ES-2200T chassis as well as a VDA card, put the VDA card in the Unit 2 position.
The DPS Personal V-Scope should always go in the Unit 2 position. Before installing two V-Scope cards in the
ES-2200T, the second V-Scope requires a custom microprocessor. If you require this custom microprocessor, contact
DPS customer service.
It is possible to install a TBC card and a MicroSYNC card together into the ES-2200T Expansion System. Some
MicroSYNC operations are not reflected on the front panel, but can still be selected. Please contact DPS for more
information.
