Broadcast DPS ES-2200 - Figure 5-3: Controlling Two ES-2200 Units

53
Figure 5-3: Controlling Two ES-2200 Units
ES-2200 #1
ES-2200 #2
Unit 1
TBC Card
Unit 2
TBC Card
Unit 3
TBC Card
Unit 4
V-Scope
Ribbon Cable Daisy Chain
(User Supplied)
RS-232 Daisy Chain
DB-9-M
DB-9-M
DB-9-F
DB-9-M
Power Supply
Power Supply
DIPSwitches
3 UP
4 UP
5 UP
6 UP
7 UP
ES-2200T
DIP Switches
1 UP
2 UP
3 UP
4 UP
5 UP
ES-2200T
DIP Switches
1 UP
2 DOWN
3 DOWN
4 DOWN
5 DOWN
Computer Control
DIP Switches
3 DOWN
4 DOWN
5 DOWN
6 DOWN
7 DOWN
DIP Switches
3 DOWN
4 DOWN
5 DOWN
6 DOWN
7 UP
ES-2200S
DIP Switches
2 UP
3 DOWN
4 DOWN
5 DOWN
6 DOWN
ES-2200S
DIP Switches
2 UP
3 UP
4 UP
5 UP
6 UP
