TBC IV Configuration Bytes

There are two bytes that carry all of the MicroSYNC Configuration information.

Configuration Byte #1 Configuration Byte #2

Bit 0 Input Mode Bit 0 Force Black

0 = NTSC 0 = Normal

1 = SVHS 1 = Force Black

Bit 1 Monochrome Mode

0 = Chroma ON

1 = Chroma Off

Bit 2 Comb Filter

0 = ON

1 = Off

Bit 3 Reference Termination

0 = Open

1 = 75 Ohm

Bit 4 Vertical Blanking

0 = Narrow

1 = Wide

Bit 5 Genlock Mode

0 = Int

1 = Auto

Bit 6 Hot Switch

0 = Disable

1 = Enable

Bit 7 Burst Enable

0 = Enable

1 = Disable
