Tri-Mode Storage Adapter Technical Specifications
Operating and Nonoperating Conditions
The following table lists the operating (thermal and atmospheric) conditions and nonoperating (such as storage and
transit) environment for the storage adapters. The minimum airflow, measured as linear feet per minute (LFPM)
at 55°C, must be met to avoid operating the controller’s processor and board components above their maximum
junction temperatures.
Table 26: Operating and Nonoperating Conditions
Operating Conditions Nonoperating Environment
Adapter
Relative Humidity
Range (Noncondensing)
Minimum
LFPM
Temperature
Range
a
Relative Humidity
Range (Noncondensing)
Temperature
Range
9560-16i 5% to 90% 200 0°C to +55°C 5% to 95% –40°C to +70°C
9560-8i 5% to 90% 200 0°C to +55°C 5% to 95% –40°C to +70°C
9580-8i8e 5% to 90% 200 0°C to +55°C 5% to 95% –40°C to +70°C
9500-16i 5% to 90% 150 0°C to +55°C 5% to 95% –40°C to +70°C
9500-8i 5% to 90% 150 0°C to +55°C 5% to 95% –40°C to +70°C
9500-16e 5% to 90% 150 0°C to +55°C 5% to 95% –40°C to +70°C
9500-8e 5% to 90% 150 0°C to +55°C 5% to 95% –40°C to +70°C
Tri-Mode Storage Adapter Power Supply Requirements
All power is supplied to the tri-mode storage adapter through the PCIe 3.3V rails and the 12V rail. Onboard switching
regulator circuitry that operates from the 3.3V rails and the 12V rail provides the necessary voltages. The following states
describe the typical power consumption of the adapters.
Typical power is measured with maximum I/O traffic, typical silicon process material, and nominal voltages operating the
card at an ambient temperature of 45°C with required airflow.
The supply voltages supplied by the PCIe edge connector are 12V ± 8% and 3.3V ± 9%.
MegaRAID Tri-Mode Storage Adapter Power Supply Requirements
The following table describes the typical power consumption of the MegaRAID adapters.
Table 27: MegaRAID Tri-Mode Storage Adapter Typical Power Consumption
Typical Power (W)
Power Mode
9560-16i 9560-8i 9580-8i8e
3.3V Supply 0.22 0.22 0.66
+12V Supply 12.99 9.42 13.59
Total Power 13.21 9.64 14.25
a. For adapters with a CVPM, this range applies with or without the CVPM attached.
Broadcom 95xx-MR-HBA-Tri-Mode-UG104
33
